High Precision Load Cell for Precision Scale Instrument 2.5KG-50KG Cantilever Beam Type Weighing Sensor Module for DIY Electronic(30KG)
Product details
| Management number | 221500042 | Release Date | 2026/05/03 | List Price | $23.50 | Model Number | 221500042 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Product DescriptionRated Capacity 2.5KG 5KG 10KG 20KG 30KG 50KGProtection grade IP65Accuracy C3Comprehensive error ± 0.02%FSCreep in 30 min ± 0.0167%FSThe Effect of Temperature on OutputSensitivity ± 0.0175%FSTemp. influence on the zero point output ± 0.015%FSZero point output ± 2.0%FSTemperature compensation range -10-40Permitted useful temperature range -35-65Input impedance 406±6Output impedance 350±3Insulation Resistance 5000 (50vdc)Recommended excitation voltage 5-12VMaximum excitation voltage 18VExtreme overload range 300%F.S
- Rated Capacity 2.5KG 5KG 10KG 20KG 30KG 50KG Protection grade IP65
- Accuracy C3 Comprehensive error ± 0.02%FS
- Creep in 30 min ± 0.0167%FS The Effect of Temperature on Output
- Sensitivity ± 0.0175%FS Temp. influence on the zero point output ± 0.015%FS
- Zero point output ± 2.0%FS Temperature compensation range -10-40
- Permitted useful temperature range -35-65 Input impedance 406±6
| Color | Silver |
|---|---|
| Brand Name | JCKJEDAT |
| Part Number | TFBAVTBFU-SILVER-30KG |
| Manufacturer | JCKJEDAT |
| Weight Capacity Maximum | 1 Grams |
